3Genesis - Top Load Push Lock with Guide Grooves®
3Genesis - Top Load Push Lock with Guide Grooves®
Product number:
3GEN-AG-TL-PBL-G2.50-M10
Quick Links
Product information
The 3Genesis Top Load Push Lock with Guide Grooves®utilizes Guide Grooves to provide simple pin engagement, with new housing that holds the pin on top and bottom of latching plate. Top Load lock is built with (4) socket head cap screw in place of the regular screws.
Includes:
- (2) 0.5 mm pin adjustment washers
- (2) 1.0 mm pin adjustment washers
- (4) M6x25 flat head cap screws
- (1) 0.017 fl oz. tube of Loctite®
Specifications
- Lock Type: Shuttle
- Fabrication Technique: Lamination, Thermoforming
- Housing Material: N/A
- Amputation Level:Transfemoral, Transtibial
- Activity Level: N/A
- Weight Limit: 350 (159kg)
- Product Weight (g): 76
- Build Height (mm): 25
- Distal Attachment: N/A
- Warranty: 12 months from purchase date
| User: | Adult |
|---|---|
| Amputation Level: | Transfemoral (TF/AK), Transtibial (TT/BK) |
| Suspension Type: | Locks |
| Fabrication Technique: | Lamination, Thermoplastic |
| Weight Limit: | 100 kg (220 lbs), 125 kg (275 lbs), 136 kg (300 lbs), 150 kg (330 lbs), 159 kg (350 lbs) |
